Description
Configurez les mini matrices changeover comme 2 entrées vers 1 sortie ou 1 entrée vers 2 sorties. Sélectionnez-les individuellement ou reliez-les entre eux afin de créer des matrices plus grandes (jusqu’à 32 voies). En outre, activez n’importe quel matrice à l’aide de l’interface tactile intuitive.
– Fonctionnement intuitif pour passer aux signaux de secours ou partager les ressources
– 32 matrices individuelles pour réaliser un passage de 32 voies maximum
– Pas d’ordinateur portable externe ou de logiciel de routage
– Commutation audio quasi instantanée via l’interface du panneau avant
– Versions Dante et Ravenna disponibles
32x 2 by 1 switches at 48kHz (16 x 2 by 1 switches at 96kHz)
Sample rates supported
– 44.1kHz
– 48kHz
– 88.2kHz
– 96kHz
Bit Depth supported
– 16bit
– 24bit
– 32bit
Dante or Ravenna option (at time of purchase)
– AES67 compatible
– SMPTE 2110 compatible
– Fully compatible with New Dante Domain Manager (Dante option only)
AoIP inputs
– Dual 1Gbps RJ45 Dante inputs
– 1Gbps or 100Mbps operation
– User configurable for Switched or Redundant operation
– Network configuration information available via menu
Control input
– Single RJ45 100Mbs
– OSC remote control of the product
Remote Control
– Single RJ45 – NOT ethernet
– Wired remote control option on RJ45 connector
– For use with optional hardware remote controllers
– RS485 balanced TX and RX pairs
– 5V feed to connected device (up to 200mA)
Note: this connector is not compatible with standard ethernet connectors
Power input
– PoE (13W) on Primary RJ45 connector
Dante® is a registered trademark of Audinate Pty Ltd.
Ravenna is an open technology standard from ALC Network Gmbh – 2.1mm DC inputs socket for use with external 24V 2amp adaptor
– Both power inputs can be active at the same time for redundancy
Other ports
USB port is also used for product firmware updates
LCD
– 6.6” (168mm) diagonal 24—bit colour LCD with 1440 x RGB x 240 resolution
– LED backlight (adjustable brightness via software)
– Multi touch capacitive touch overlay with gesture support
Product Size
– Dimensions 494mm x 120mm x 44mm
– Weight 1.0kg
– 19inch rack mounting ears can be removed for desktop use
